High-speed mirror precision mirror spark machine PLS-N45S
Category:
N series
Summary:
Optimal surface roughness 0.2 μm and wear-resistant stainless steel material with tool lift height control
Keyword:
Previous page
None
Next page
Description
Features
● Fine edge processing
● Anti-carbon deposition function
● Best surface roughness 0.2 μm
● Stainless steel material wear resistance and tool height control
● CNC system touch screen input, hand-held box operation
● X/Y/Z three axes adopt Taiwan imported C5 grade double nut ball screw
● X/Y/Z three axes all adopt Japan original "Panansonic" AC servo motor
Specifications and parameters
| Model/Item | PLS-N45S |
| Working tank size (mm) | 990*600*350 |
| Worktable size (mm) | 700*400 |
| Working stroke XYZ (mm) | 450*350*300 |
| Z-axis distance from worktable high and low points (mm) | 320-620 |
| Maximum processing electrode weight (kg) | 100 |
| Maximum workpiece weight (kg) | 400 |
| Minimum drive unit (mm) | 0.001 |
| Machine weight (approx. KG) | 2300 |
| Immersion oil tank standard capacity (L) | 450 |
| Electromechanical integrated external dimensions (mm) | 1900*2000*2300 |
| Standard configuration | Automatic fire extinguishing device, electrode chuck, filter element, toolbox, instruction manual, work lamp |
| Optional configuration | EDM fluid, flexible quick fixture, magnetic chuck |
*Standard and optional configurations may vary depending on the version. Our company reserves the right to change product technical parameters, equipment, optional parts, and colors at any time based on the principle of continuous product development.
*These parameters provide general information and do not constitute a contractual document.
